GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female Pigtail for IAT Part # CONN-85643

GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female Pigtail for IAT GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female Pigtail for IAT
Pricing
1 + $5.99
5 + $5.75
25 + $5.49
50 + $5.25
100 + $4.99
1000 + $4.99
Information
Bmotorsports Part # CONN-85643
Availability In Stock
Shipping Weight 0.05 Lbs.
Shipping Location VA   (Shipping Info)
Ship Estimator Quantity:

Description

GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female Pigtail for IAT


Associated & Mating Parts

Relationship Part # Description
Preferred Connector (Shrouded with rear release):
Connector Only CONN-51560GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female assembly for IAT
Terminals CONN-56468GM Delphi / Packard - GT 150 3.5mm Centerline Female Terminal, 18 gauge [ .75 - .8mm2] Tin Plated
Seals CONN-56559GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only
Connector Kit CONN-75643GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female Kit for IAT
Connector Pigtail CONN-85643GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female Pigtail for IAT
Non-preferred Connector (Unshrouded with front release):
Connector Only CONN-51561GM Delphi / Packard - 2-way un-shrouded GT 150 3.5mm centerline sealed female assembly for IAT
Terminals CONN-56468GM Delphi / Packard - GT 150 3.5mm Centerline Female Terminal, 18 gauge [ .75 - .8mm2] Tin Plated
Seals CONN-56559GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only
Connector Kit CONN-75644GM Delphi / Packard - 2-way Un-shrouded GT 150 3.5mm centerline sealed female Kit for IAT
Connector Pigtail CONN-85644GM Delphi / Packard - 2-way un-shrouded GT 150 3.5mm centerline sealed female Pigtail for IAT
Obsoleted Connector (still available for sale):
Connector Only CONN-51555GM Delphi / Packard 2 way IAT / MAT / ACT Sensor Connector (connector only)
Terminals CONN-56155GM Delphi / Packard - 150.2 Metri-Pack ( Metripack ) Female Terminal ( 22 - 18 gauge ) [Pull to seat]
Connector Kit CONN-75555GM Delphi / Packard - 2 way IAT / MAT / ACT Sensor Connector Kit
Connector Pigtail CONN-85555GM Delphi / Packard 2 way IAT / MAT / ACT Sensor Connector Pigtail # 12102620
Mating Connector
Connector Only CONN-50564GM Delphi / Packard - 2-way GT 150 3.5mm centerline (sensor side) sealed connector assembly for IAT
Connector Kit CONN-75774GM Delphi / Packard - 2-way GT 150 3.5mm centerline (sensor side) sealed connector Kit for IAT
Connector Pigtail CONN-85774GM Delphi / Packard - 2-way GT 150 3.5mm centerline (sensor side) sealed connector Pigtail for IAT
Extensions
IAT / MAT / ACT Wiring Extension CONN-85584GM Delphi / Packard - IAT / MAT / ACT Extender Harness
Mating sensors:
Fast Response 3/8 NPT IAT SNSR-02057Fast-Response GM Delphi / Packard Intake Air Temperature Sensor ( IAT / MAT / ACT ) or Manifold Air Temperature Sensor # 25036751 - 25037225 - 25037034 *RECOMMENDED*
Fast Response M14x1.5 IAT SNSR-02063Fast-Response (Metric M14 x 1.5) GM Delphi / Packard Intake Air Temperature Sensor ( IAT / MAT / ACT ) or Manifold Air Temperature Sensor
Fast Response Grommet IAT SNSR-02060GM Delphi / Packard Intake Air Temperature Sensor ( IAT / MAT / ACT) or Manifold Air Temperature Sensor, Black with Keyway Connector
Standard Response Plastic IAT SNSR-02058GM Delphi / Packard Intake Air Temperature Sensor ( IAT / MAT / ACT) or Manifold Air Temperature Sensor # 12146830 , Gray with Keyway Connector

Applications

Cross References:

  • Equivalent to ACDelco Pigtail PT1495 & GM Pigtail Part# 15306430
  • Compatible with ACDelco Pigtail PT307 & GM Pigtail Part# 12102620
  • Compatible with ACDelco Pigtail PT1158 & GM Pigtail Part# 15306031


Specifications

Parameter Value
Number of Ways2
GenderPlug/Male
Terminal Size1.5mm
Terminal TypeFlat
Min. Wire Gauge18
Max. Wire Gauge18



This product contains the following items:
20AWG Automotive TXL Wire Black» 1 x 20AWG Automotive TXL Wire Black
Part # WIRE-00458S
20AWG Automotive TXL Wire Yellow» 1 x 20AWG Automotive TXL Wire Yellow
Part # WIRE-04458S
Labor $0.25/minute» 10 x Labor $0.25/minute
Part # LABR-00001
GM Delphi / Packard - GT 150 3.5mm Centerline Female Terminal, 18 gauge [ .75 - .8mm2] Tin Plated» 2 x GM Delphi / Packard - GT 150 3.5mm Centerline Female Terminal, 18 gauge [ .75 - .8mm2] Tin Plated
Part # CONN-56468
GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only» 2 x GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only
Part # CONN-56559
TPA for 2-way GT 150 3.5mm centerline (sensor side) sealed connector assembly» 1 x TPA for 2-way GT 150 3.5mm centerline (sensor side) sealed connector assembly
Part # CONN-50558
GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female for IAT» 1 x GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female for IAT
Part # CONN-51558
