    Fuel Bulkhead Connector Kit Only Part # CONN-76201

    Fuel Bulkhead Connector Kit Only Fuel Bulkhead Connector Kit Only Fuel Bulkhead Connector Kit Only
    Pricing
    1 + $34.99
    25 + $33.99
    100 + $29.99
    250 + Call for Pricing
    Information
    Bmotorsports Part # CONN-76201
    Availability In Stock
    Shipping Weight 0.1 Lbs.
    Shipping Location VA   (Shipping Info)
    Ship Estimator Quantity:

    Description

    Fuel Bulkhead Connector Kit Only. Terminals and seals ARE included.

    This kit allows you to pass through six signal wires into fuel tanks to power single, or dual pumps and a level sender, through a specified fitting.
    COMING SOON are weld-in and unique bolt-in style fittings, snap ring, etc to use with these parts for a complete installation as an all-in-one kit.


    Associated & Mating Parts

    Relationship Part # Description
    Associated Parts
    6 Way Fuel Connector Plug CONN-1009586 Way Fuel Pump Connector Plug for Bulkhead Connection
    Female 2.8mm Terminal 16-14AWG CONN-100463Female 2.8mm Terminal 16-14AWG
    6 Way Fuel Connector Plug, Seals Removed CONN-1012216 Way In-Tank Fuel Pump Connector for Bulkhead Connection
    Cavity Plug CONN-56158GM Delphi / Packard - Metripack 150.2 Seal Plug for hand insertion (with tail)
    Mating Parts
    6 Way Fuel Tank Bulkhead Passthrough Connector Receptacle CONN-1009496 Way Fuel Tank Bulkhead Passthrough Connector Receptacle Assembly
    Male 2.8mm Terminal 16-14AWG CONN-100462Male terminal for 3-way Headlight receptacle connector
    Bolt Type Fuel Bulkhead Kit CONN-76071
    Weld Type Fuel Bulkhead Kit CONN-76072
    Fuel Bulkhead Connector Kit Only CONN-76201Fuel Bulkhead Connector Kit Only
    Bolt Type Fuel Bulkhead Kit with Pigtails CONN-86071
    Weld Type Fuel Bulkhead Kit with Pigtails CONN-86072

    This product contains the following items:
    GM Delphi / Packard - Metripack 150.2 Seal Plug for hand insertion (with tail)» 4 x GM Delphi / Packard - Metripack 150.2 Seal Plug for hand insertion (with tail)
    Part # CONN-56158
    Female 2.8mm Terminal 16-14AWG» 14 x Female 2.8mm Terminal 16-14AWG
    Part # CONN-100463
    6 Way Fuel Tank Bulkhead Passthrough Connector Receptacle» 1 x 6 Way Fuel Tank Bulkhead Passthrough Connector Receptacle
    Part # CONN-100957
    6 Way Fuel Pump Connector Plug for Bulkhead Connection» 1 x 6 Way Fuel Pump Connector Plug for Bulkhead Connection
    Part # CONN-100958
    6 Way In-Tank Fuel Pump Connector for Bulkhead Connection» 1 x 6 Way In-Tank Fuel Pump Connector for Bulkhead Connection
    Part # CONN-101221
    Flex Fuel O-Ring for Fuel Bulkhead passthrough» 1 x Flex Fuel O-Ring for Fuel Bulkhead passthrough
    Part # MOTR-100537
