GM Delphi / Packard - 2-way GT 150 3.5mm centerline (sensor side) sealed connector Pigtail for IAT	Part # CONN-85774

Pricing
1 +	$9.99
5 +	$8.99
25 +	$8.49
50 +	$7.49
100 +	$5.99
1000 +	$4.99
Information
Bmotorsports Part #	CONN-85774
Availability	In Stock
Shipping Weight	0.05 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

GM Delphi / Packard - 2-way GT 150 3.5mm centerline (sensor side) sealed connector Pigtail for IAT

Associated & Mating Parts

Relationship	Part #	Description
Associated Connectors
Connector Only	CONN-50564	GM Delphi / Packard - 2-way GT 150 3.5mm centerline (sensor side) sealed connector assembly for IAT
Terminals	CONN-56466	GM Delphi / Packard - GT 150 3.5mm Centerline Male Terminal, 18 gauge [ .75 - .8mm2] Tin Plated
Seals	CONN-56559	GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only
Connector Kit	CONN-75774	GM Delphi / Packard - 2-way GT 150 3.5mm centerline (sensor side) sealed connector Kit for IAT
Connector Pigtail	CONN-85774	GM Delphi / Packard - 2-way GT 150 3.5mm centerline (sensor side) sealed connector Pigtail for IAT
Preferred Mating Connector (Shrouded with rear release):
Connector Only	CONN-51560	GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female assembly for IAT
Terminals	CONN-56468	GM Delphi / Packard - GT 150 3.5mm Centerline Female Terminal, 18 gauge [ .75 - .8mm2] Tin Plated
Seals	CONN-56559	GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only
Connector Kit	CONN-75643	GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female Kit for IAT
Connector Pigtail	CONN-85643	GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female Pigtail for IAT
Non-preferred Mating Connector (Unshrouded with front release):
Connector Only	CONN-51561	GM Delphi / Packard - 2-way un-shrouded GT 150 3.5mm centerline sealed female assembly for IAT
Terminals	CONN-56468	GM Delphi / Packard - GT 150 3.5mm Centerline Female Terminal, 18 gauge [ .75 - .8mm2] Tin Plated
Seals	CONN-56559	GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only
Connector Kit	CONN-75644	GM Delphi / Packard - 2-way Un-shrouded GT 150 3.5mm centerline sealed female Kit for IAT
Connector Pigtail	CONN-85644	GM Delphi / Packard - 2-way un-shrouded GT 150 3.5mm centerline sealed female Pigtail for IAT
Extensions
IAT / MAT / ACT Wiring Extension	CONN-85584	GM Delphi / Packard - IAT / MAT / ACT Extender Harness

Specifications

Parameter Value
Number of Ways 2
Gender Receptacle/Female
Terminal Size 1.5mm
Terminal Type Flat
Min. Wire Gauge 18
Max. Wire Gauge 18

This product contains the following items:
	» 2 x 20AWG Automotive TXL Wire Black Part # WIRE-00458S
	» 10 x Labor $0.25/minute Part # LABR-00001
	» 2 x GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only Part # CONN-56559
	» 2 x GM Delphi / Packard - GT 150 3.5mm Centerline Male Terminal, 18 gauge [ .75 - .8mm2] Tin Plated Part # CONN-56466
	» 1 x GM Delphi / Packard - 2-way GT 150 3.5mm centerline (sensor side) sealed connector for CLT/VSS Part # CONN-50557
	» 1 x Insert for 2-way connector for IAT / MAT / ACT Connector ( Sensor Side ) Part # CONN-50563
