3 Way Plug Connector Pigtail for BMW Sensors	Part # CONN-86194

Pricing
1 +	$12.99
25 +	$11.99
100 +	$11.49
1000 +	Call for Pricing
Information
Bmotorsports Part #	CONN-86194
Availability	In Stock
Shipping Weight	0.005 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

3 Way Plug Connector Pigtail for BMW Sensors. Connector Pigtail. A completed pigtail is provided with 305mm / 12" leads.

This plug housing connects to an enormous amount of sensors and solenoids on modern F platform BMW chassis, additionally used on many connections for BMW Motorrad cycles.

Associated & Mating Parts

Relationship	Part #	Description
Associated Connectors
Connector Plug Only	CONN-100847	3 Way Plug Connector for BMW Sensors
Terminals	CONN-100713	Female Terminal for C7 Corvette oxygen sensor Connector Plug 20-18AWG (0.5 - 0.8mm2)
Seals	CONN-00193	Seals for Bosch wide flat connector for LSU 4.0 and LSU 4.9 sensor
Connector Kit	CONN-76194	3 Way Plug Connector Kit for BMW Sensors
Connector Pigtail	CONN-86194	3 Way Plug Connector Pigtail for BMW Sensors
Mating Connectors
Connector Receptacle Only	CONN-101245	3 Way Connector Receptacle for BMW Sensors
Terminals	CONN-100714	Male Terminal for C7 Corvette oxygen sensor Connector Receptacle 20-18AWG (0.5 - 0.8mm2)
Seals	CONN-00193	Seals for Bosch wide flat connector for LSU 4.0 and LSU 4.9 sensor
Connector Kit	CONN-76196	3 Way Connector Receptacle Kit for BMW Sensors
Connector Pigtail	CONN-86196	3 Way Connector Receptacle Pigtail for BMW Sensors

Applications

Applications:

BMW F30 N55 High Pressure Pump Position Sensor Connector B270*1B
BMW F30 N55 Intake Camshaft Position Sensor Connector B6210*1B
BMW F30 N55 Crankshaft Sensor Connector X703*1B
F30 N55 Engine Oil Pressure Sensor Connector B268*1B:
F30 N55 Vacuum Leak Detection temperature sensor and pressure switch Connector A248*1B
F30 N55 Exhaust Camshaft Position Sensor Connector B6210*1B
Many other applications not listed

Specifications

Parameter Value
Number of Ways 3
Gender Plug/Male
Terminal Size 1.2mm
Terminal Type Flat
Min. Wire Gauge 18
Max. Wire Gauge 20

This product contains the following items:
	» 15 x Labor $0.25/minute Part # LABR-00001
	» 3 x 18AWG Automotive TXL Wire Black Part # WIRE-00459s
	» 3 x Seals for Bosch wide flat connector for LSU 4.0 and LSU 4.9 sensor Part # CONN-00193
	» 3 x Female Terminal for C7 Corvette oxygen sensor Connector Plug 20-18AWG (0.5 - 0.8mm2) Part # CONN-100713
	» 1 x 3 Way Plug Connector for BMW Sensors Part # CONN-100847
