    LSA Supercharger Lid IAT Breakout for LS Truck Harness, Trailblazer SS Part # CONN-86136

    LSA Supercharger Lid IAT Breakout for LS Truck Harness, Trailblazer SS LSA Supercharger Lid IAT Breakout for LS Truck Harness, Trailblazer SS LSA Supercharger Lid IAT Breakout for LS Truck Harness, Trailblazer SS LSA Supercharger Lid IAT Breakout for LS Truck Harness, Trailblazer SS
    Pricing
    1 + $39.99
    Information
    Bmotorsports Part # CONN-86136
    Availability In Stock
    Shipping Weight 0.25 Lbs.
    Shipping Location VA   (Shipping Info)
    Ship Estimator Quantity:

    Description

    "THE COVERMAN SPECIAL for LS2 TRAILBLAZER AND LS TRUCK MAF's!" inspired by Coverman66 for his LSA brick swap project videos.

    LSA Supercharger Lid IAT Breakout for LS Truck Harness, Trailblazer SS. If you are swapping an LSA Supercharger intake manifold or an LSA complete swap into a variety of applications, you will want to use the IAT on the Supercharger Lid. This is the Coverman66 special harness with instructional video here . If you want just the IAT pigtail, it is CONN-85643.

    Hi-temp Nylon Braided sleeving, genuine OEM connector plugs, seals, cavity plugs & terminals, manufactured and assembled at our facility in the US. This MAF Connector mate is aftermarket only though made in the US.


    Associated & Mating Parts

    Relationship Part # Description
    Associated Parts
    Terminals CONN-56468GM Delphi / Packard - GT 150 3.5mm Centerline Female Terminal, 18 gauge [ .75 - .8mm2] Tin Plated
    Seals CONN-56559GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only
    Connector Housing CONN-518665 Way GM MAF Connector Plug Assembly for LS2, LS6, Truck, & some LS1
    Connector Kit CONN-756495 Way GM MAF Connector Plug Kit for LS2, LS6, Truck, & some LS1
    Connector Pigtail CONN-856495 Way GM MAF Connector Plug Pigtail for LS2, LS6, Truck, & some LS1
    Associated Parts
    Terminals CONN-100730Pull to seat Male Terminal for 150.2 & GT 150 3.5mm receptacles in 3,4,5,6 way
    Seals
    Connector Only CONN-1007285 Way Connector Receptacle for MAF & Sensor Applications
    Connector Kit CONN-758625 Way Connector Receptacle Kit for MAF & Sensor Applications
    Connector Pigtail CONN-858625 Way Connector Receptacle Pigtail for MAF & Sensor Applications
    Associated Parts
    Connector Only CONN-51560GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female assembly for IAT
    Terminals CONN-56468GM Delphi / Packard - GT 150 3.5mm Centerline Female Terminal, 18 gauge [ .75 - .8mm2] Tin Plated
    Seals CONN-56559GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only
    Connector Kit CONN-75643GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female Kit for IAT
    Connector Pigtail CONN-85643GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female Pigtail for IAT

    Applications

    • Cadillac CTS-V LSA Engine
    • Camaro ZL1 LSA Engine
    • GM Crate LSA Engine
