GM Delphi / Packard Fluid Temperature Sensor ( ECT / CLT / TFT ) or Coolant Temperature Sensor M12 x 1.5 Pigtail Kit	Part # SNSR-02059PK

Pricing
1 +	$17.00
5 +	$16.49
10 +	$15.99
25 +	$15.49
50 +	$14.99
100 +	$13.99
250 +	$11.99
Information
Bmotorsports Part #	SNSR-02059PK
Availability	In Stock
Shipping Weight	0.035 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

GM Delphi / Packard Fluid Temperature Sensor ( ECT / CLT / TFT ) or Coolant Temperature Sensor M12 x 1.5 Pigtail Kit

FEATURES:

Genuine Delphi Sensor
Robust Design
Cost Effective
100% Calibration Certified
Thermistor Technology
Typical Voltage Supply: 5V DC
Operating Temperature: -40 C to 135 C
Sensor Body Material: Brass
Hex Size: 18.90 mm (3/4")
Thread Size: M12 x 1.5
Thread Sealant: GM09985490
Sealing Pressure: 145 kPa
Thermal Time Constant: ** 18 to 24 seconds
Dissipation Constant: * 24 mW/degC

Cross References:

Motec: 55001
AC Delco: 213-4333
AC Delco: 213-953
ACDelco 213-4514
GM: 15326388
GM: 12608814
Delphi: TS10076
Most aftermarket ECU's on the market such as Haltech, Electromotive, Autronic, Bigstuff3, etc.
VERY common sensor with hundreds of other applications

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts:
3/8 NPT ECT / CLT / TFT	SNSR-02056	GM Delphi / Packard Fluid Temperature Sensor ( ECT / CLT / TFT ) or Coolant Temperature Sensor # 15326386 / 25036979
M12 x 1.5 ECT / CLT / TFT	SNSR-02059	GM Delphi / Packard Fluid Temperature Sensor ( ECT / CLT / TFT ) or Coolant Temperature Sensor M12 x 1.5
3/8 NPT IAT / MAT / ACT Plastic	SNSR-02055	GM Delphi / Packard Intake Air Temperature Sensor ( IAT / MAT / ACT) or Manifold Air Temperature Sensor # 12110446 , Black with Mushroom Connector
Preferred Mating Connector (Shrouded with rear release):
Connector Only	CONN-51662	GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female assembly for CLT/VSS (connector plus TPA)
Terminals	CONN-56468	GM Delphi / Packard - GT 150 3.5mm Centerline Female Terminal, 18 gauge [ .75 - .8mm2] Tin Plated
Seals	CONN-56559	GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only
Connector Kit	CONN-75641	GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female Kit for CLT/VSS
Connector Pigtail	CONN-85641	GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female Pigtail for CLT/VSS
Non-preferred Mating Connector (Unshrouded with front release):
Connector Only	CONN-51663	GM Delphi / Packard - 2-way un-shrouded GT 150 3.5mm centerline sealed female assembly for CLT/VSS (connector plus TPA)
Terminals	CONN-56468	GM Delphi / Packard - GT 150 3.5mm Centerline Female Terminal, 18 gauge [ .75 - .8mm2] Tin Plated
Seals	CONN-56559	GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only
Connector Kit	CONN-75642	GM Delphi / Packard - 2-way un-shrouded GT 150 3.5mm centerline sealed female Kit for CLT/VSS
Connector Pigtail	CONN-85642	GM Delphi / Packard - 2-way un-shrouded GT 150 3.5mm centerline sealed female pigtail for CLT/VSS
Extensions
ECT / CLT / TFT Preferred Wiring Extension	CONN-85645-shroud	GM Delphi / Packard - ECT / CLT / TFT / VSS / ISS / OSS Extender Harness, Shrouded connectors
ECT / CLT / TFT Wiring Extension	CONN-85645-unshroud	GM Delphi / Packard - ECT / CLT / TFT / VSS / ISS / OSS Extender Harness, Un-shrouded connector

Specifications

» 1 x GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female Pigtail for CLT/VSS
» GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female Pigtail for CLT/VSS
     1 x 20AWG Automotive TXL Wire Black
     20AWG Automotive TXL Wire Black
     1 x 20AWG Automotive TXL Wire Yellow
     20AWG Automotive TXL Wire Yellow
     10 x Labor $0.25/minute
     Labor $0.25/minute
     2 x GM Delphi / Packard - GT 150 3.5mm Centerline Female Terminal, 18 gauge [ .75 - .8mm2] Tin Plated
     GM Delphi / Packard - GT 150 3.5mm Centerline Female Terminal, 18 gauge [ .75 - .8mm2] Tin Plated
     2 x GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only
     GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only
     1 x GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female connector for CLT/VSS
     GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female connector for CLT/VSS
     1 x TPA for 2-way GT 150 3.5mm centerline (sensor side) sealed connector assembly
     TPA for 2-way GT 150 3.5mm centerline (sensor side) sealed connector assembly

This product contains the following items:
	» 1 x GM Delphi / Packard Fluid Temperature Sensor ( ECT / CLT / TFT ) or Coolant Temperature Sensor M12 x 1.5 Part # SNSR-02059
