    Tundra LED Retrofit Headlight harness Part # CONN-86070

    Tundra LED Retrofit Headlight harness Tundra LED Retrofit Headlight harness Tundra LED Retrofit Headlight harness Tundra LED Retrofit Headlight harness Tundra LED Retrofit Headlight harness
    Pricing
    1 + $49.99
    Information
    Bmotorsports Part # CONN-86070
    Availability In Stock
    Shipping Weight 0.25 Lbs.
    Shipping Location VA   (Shipping Info)
    Ship Estimator Quantity:

    Description

    Headlight harness. This allows you to use new 2018 Tundra 8-pin LED Headlights, when paired with this HID relay kit. You will need 1 CONN-86070 harness for the drivers side and 1 for the passenger side light, for a total of 2 per vehicle. This is true Plug and Play with all trim level 2014-2017 Tundras for use with 2018 LED headlamps! If you require a harness that is a straight adapter to LED housings (no relay kit), please see part number CONN-86255

    ***For SR/SR5/Limited/Pro trim level Tundra's, and trucks that do not have factory DRL's (Daytime running lights), more work is required to enable DRL's, and sidemarker bulbs for 100% functionality. Please check the following community forum link for more information regarding these other trim levels and factory non-DRL trucks. ***

    16AWG automotive TXL wire construction, Hi-temp Nylon Braided sleeving, genuine OEM connector plugs, seals, cavity plugs & terminals, manufactured and assembled at our facility in the US.


    Associated & Mating Parts

    Relationship Part # Description
    Associated MP280 Parts
    18-16 AWG Terminals CONN-55855GM Delphi / Packard - Male Metripack 280 Terminal, 18-16 gauge
    14-12 AWG Terminals CONN-55856GM Delphi / Packard - Male Metripack 280 Terminal, 14-12 gauge
    12-10 AWG Terminals CONN-55857
    18-16 AWG Seals CONN-55557GM Delphi / Packard - Weatherpack/Metripack 280 2.8-2.03mm Cable Seal, Green - 18-14 gauge
    14-12 AWG Seals CONN-55559GM Delphi / Packard - Weatherpack/Metripack 280 4.3-3.45mm Cable Seal, Blue - (12-10 gauge)
    Connector Housing CONN-100792GM Delphi / Packard - 2 Way Metripack 280 Connector Receptacle for 9006 / H7 / HB4 Headlight Bulb
    Connector Kit CONN-75893GM Delphi / Packard - 2 Way Metripack 280 Connector Receptacle Kit for 9006 / H7 / HB4 Headlight Bulb
    Pigtail CONN-85893GM Delphi / Packard - 2 Way Metripack 280 Connector Receptacle Pigtail for 9006 / H7 / HB4 Headlight Bulb
    Mating MP280 Parts
    18-16 AWG Terminals CONN-55955GM Delphi / Packard - Female Metripack 280 Terminal, 18-16 gauge
    14-12 AWG Terminals CONN-55956GM Delphi / Packard - Female Metripack 280 Terminal, 14-12 gauge
    12-10 AWG Terminals CONN-55957GM Delphi / Packard - Female Metripack 280 Terminal, 12-10 gauge
    20-16 AWG Seals CONN-55560GM Delphi / Packard - Weather-Pack ( Weatherpack ) Cable Seal ( 20 - 16 gauge ) ( purple )
    18-16 AWG Seals CONN-55557GM Delphi / Packard - Weatherpack/Metripack 280 2.8-2.03mm Cable Seal, Green - 18-14 gauge
    14-12 AWG Seals CONN-55559GM Delphi / Packard - Weatherpack/Metripack 280 4.3-3.45mm Cable Seal, Blue - (12-10 gauge)
    Cavity Plug CONN-55555GM Delphi / Packard - Weatherpack/Metripack 280 Cavity Plug
    Connector Housing CONN-100047GM Delphi / Packard - 2 Way Metripack 280 Connector Plug for 9006 / H7 / HB4 Headlight Bulb
    Connector Kit CONN-75669GM Delphi / Packard - 2 Way Metripack 280 Connector Plug Kit for 9006 / H7 / HB4 Headlight Bulb
    Pigtail CONN-85669GM Delphi / Packard - 2 Way Metripack 280 Connector Plug Pigtail for 9006 / H7 / HB4 Headlight Bulb
    Associated Yazaki Parts
    20-16 AWG Terminals CONN-11856Sumitomo TS / SL Female Terminal 0.5 - 1.25 mm2 ( 20 - 16 AWG )
    22-20 AWG Terminals CONN-11857Yazaki Female Terminals for 2 way 090 IAT / MAT Connector ( 22 - 20 AWG )
    22-18 AWG Seals CONN-00146Sumitomo HM / MT / TS Sealed Series wire seal, brown( 22 - 18 gauge )
    20-16 AWG Seals CONN-00145Sumitomo HM / MT / TS Sealed Series wire seal, black ( 20 - 16 gauge )
    Cavity Plug CONN-100550Sumitomo MT / TS / HX / SL Sealed Series Cavity plug, black 7160-9465
    Connector Housing CONN-1008514 Way Connector Plug for Toyota & Subaru Oxygen Sensor, 90980-10869
    Connector Housing CONN-1008524 Way Connector Receptacle for Toyota & Subaru Oxygen Sensor, 90980-10868
    Headlight Connector Housing CONN-1010178 Way Japanese Connector Plug for Headlight Applications Toyota # 90980-10897
    Connector Kit CONN-759284 Way Connector Plug Kit for Toyota & Subaru Oxygen Sensor, 90980-10869
    Connector Kit CONN-759294 Way Connector Receptacle Kit for Toyota & Subaru Oxygen Sensor, 90980-10868
    Headlight Connector Kit CONN-760678 Way Japanese Connector Plug Kit for Headlight Applications Toyota # 90980-10897
    Pigtail CONN-859284 Way Connector Plug Pigtail for Toyota & Subaru Oxygen Sensor, 90980-10869
    Pigtail CONN-859294 Way Connector Receptacle Pigtail for Toyota & Subaru Oxygen Sensor, 90980-10868

    Applications

    • 2014-2017 Toyota Tundra 1794/Platinum models with factory LED DRLs Headlight Retrofit to
    • 2018 Toyota Tundra LED Headlamp


    Specifications

    Parameter Value
    Terminal Size2.3mm
    Terminal Size (Secondary)2.3mm
    Terminal Size (Tertiary)2.8mm
    Terminal TypeFlat
    Terminal Type (Secondary)Flat
    Terminal Type (Tertiary)Flat
    Min. Wire Gauge18
    Max. Wire Gauge10
