2 Way Nissan CAM, Knock, VVT, & VCT Plug Connector Kit (Nissan # E02FG-RS)	Part # CONN-75984

Pricing
1 +	$8.99
50 +	$8.75
100 +	$8.25
Information
Bmotorsports Part #	CONN-75984
Availability	In Stock
Shipping Weight	0.05 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

2 Way Nissan CAM, Knock, VVT, & VCT Plug Connector Kit (Nissan # E02FG-RS). Connector Kit. Terminals and seals ARE included.

The 2 Way Nissan CAM, Knock, VVT, & VCT Plug Connector is an upgraded version of the original Nissan connector from the OEM manufacturer. Used on many Nissan applications as a CAM Position Sensor or CAM Angle Sensor Connector, Knock Sensor Connector, & VVT/VCT Connector.

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Terminals	CONN-100580	Sumitomo 91 Series Female Terminals .85 - 1.25mm2 (18 - 16 AWG)
Seals	CONN-100581	Sumitomo 91 Series Seals 18 - 16 AWG
Connector Housing	CONN-100914	2 Way Nissan CAM, Knock, VVT, & VCT Plug Connector (Nissan # E02FG-RS)
Connector Kit	CONN-75984	2 Way Nissan CAM, Knock, VVT, & VCT Plug Connector Kit (Nissan # E02FG-RS)
Pigtail	CONN-85984	2 Way Nissan CAM, Knock, VVT, & VCT Plug Connector Pigtail (Nissan # E02FG-RS)

Applications

Nissan CAM Connector
Nissan CAM Position Sensor Connector
Nissan CAM Angle Sensor Connector
Nissan Knock Sensor Connector
Nissan VVT Connector
Nissan # E02FG-RS
Techmate # J-48817-182
Sensor & Device Connector on many other applications

Specifications

Parameter Value
Number of Ways 2
Gender Plug/Male
Terminal Size 2.3mm
Terminal Type Flat
Min. Wire Gauge 18
Max. Wire Gauge 16

This product contains the following items:
	» 3 x Sumitomo 91 Series Female Terminals .85 - 1.25mm2 (18 - 16 AWG) Part # CONN-100580
	» 3 x Sumitomo 91 Series Seals 18 - 16 AWG Part # CONN-100581
	» 1 x Japanese Solenoid Connector lock only (no connector) Part # CONN-100604
	» 1 x 2 Way Nissan CAM, Knock, VVT, & VCT Plug Connector (Nissan # E02FG-RS) Part # CONN-100904
