4 Way Connector Receptacle Pigtail for Coils & Sensor Applications Part # CONN-85861

4 Way Connector Receptacle Pigtail for Coils & Sensor Applications 4 Way Connector Receptacle Pigtail for Coils & Sensor Applications 4 Way Connector Receptacle Pigtail for Coils & Sensor Applications
Pricing
1 + $10.99
25 + $10.49
100 + $9.99
1000 + Call for Pricing
Information
Bmotorsports Part # CONN-85861
Availability In Stock
Shipping Weight 0.075 Lbs.
Shipping Location VA   (Shipping Info)
Ship Estimator Quantity:

Description

4 Way Connector Pigtail for Coil & Sensor Applications. Connector Pigtail. Preassembled and includes connector, seals, and terminals already crimped on 12 inch wire leads. A completed pigtail is provided.

Used on many GM coil applications, and some other sensor applications.


Associated & Mating Parts

Relationship Part # Description
Associated Parts
Connector Only CONN-1007274 Way Connector Receptacle for Coils & Sensor Applications
Terminals CONN-100730Male Terminal for 150.2 & GT 150 3.5mm receptacles in 3,4,5,6 way
Connector Kit CONN-758614 Way Connector Receptacle Kit for Coils & Sensor Applications
Connector Pigtail CONN-858614 Way Connector Receptacle Pigtail for Coils & Sensor Applications
Preferred Mating Parts
Connector Only CONN-52366GM Delphi / Packard - 4 way GT 150 3.5mm Centerline male connector Assembly for some GM truck ignition coils (index keyway) (connector and TPA)
Terminals CONN-56468GM Delphi / Packard - GT 150 3.5mm Centerline Female Terminal, 18 gauge [ .75 - .8mm2] Tin Plated
Seals CONN-56559GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only
Connector Kit CONN-75636GM Delphi / Packard - 4 way GT 150 3.5mm Centerline male connector Kit for some GM truck ignition coils (index keyway)
Connector Pigtail CONN-85636GM Delphi / Packard - 4 way GT 150 3.5mm Centerline male connector Pigtail for some GM truck ignition coils (index keyway)
Non-Preferred Mating Parts
Connector Only CONN-52206GM Delphi / Packard - 4 way metripack 150.2 sealed male connector assembly for iac, black
Terminals CONN-56155GM Delphi / Packard - 150.2 Metri-Pack ( Metripack ) Female Terminal ( 22 - 18 gauge ) [Pull to seat]
Connector Kit CONN-75638GM Delphi / Packard - 4 way metripack 150.2 sealed male connector Kit for iac, black
Connector Pigtail CONN-85638GM Delphi / Packard - 4 way metripack 150.2 sealed male connector Pigtail for iac, black
Extension
Extension CONN-85889
Adapter
4 Way Bosch TMAP Sensor to GM harness adapter CONN-859344 Way Bosch TMAP Sensor to 4 Way GM TMAP Harness adapter for GM Applications

Applications

Applications:

  • GM Truck Coil (Device Side)
  • GM Map Sensor (Device Side)
  • Many other GM Sensor applications



This product contains the following items:
Labor $0.25/minute» 30 x Labor $0.25/minute
Part # LABR-00001
16AWG Automotive TXL Wire Black» 4 x 16AWG Automotive TXL Wire Black
Part # WIRE-00460s
Male Terminal for 150.2 & GT 150 3.5mm receptacles in 3,4,5,6 way» 4 x Male Terminal for 150.2 & GT 150 3.5mm receptacles in 3,4,5,6 way
Part # CONN-100730
4 Way Connector Receptacle for Coils & Sensor Applications» 1 x 4 Way Connector Receptacle for Coils & Sensor Applications
Part # CONN-100727
