NA Miata 64 way ECU Header Receptacle	Part # CONN-100747

Pricing
1 +	$29.99
Information
Bmotorsports Part #	CONN-100747
Availability	In Stock
Shipping Weight	0.1 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

NA Miata 64 way ECU Header Receptacle. Connector ONLY. Terminals not included.

This is the header connector which is normally soldered directly to the ECU circuit board of an NA (first generation) Miata MX-5. Sometimes these break or a user needs to make a new harness or a new ECU connection.
This item may take an additional 2-5 days to ship.

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
64 Way Header	CONN-100747	NA Miata 64 way ECU Header Receptacle
Mating Parts
Small Terminals	CONN-100748	ECU Female Terminals, 0.3mm2 - 0.5mm2 ( 22 - 20 AWG)
Large Terminals	CONN-100011	ECU Female Terminals, 0.4mm2 - 1.4mm2 ( 20 - 16 AWG)
16 Way Connector	CONN-100744	NA Miata 16 Way ECU Plug
22 Way Connector	CONN-100745	NA Miata 22 Way ECU Plug
26 Way Connector	CONN-100746	NA Miata 26 Way ECU Plug
16 Way Connector Kit	CONN-75907	NA Miata 16 Way ECU Plug Kit
22 Way Connector Kit	CONN-75908	NA Miata 22 Way ECU Plug Kit
26 Way Connector Kit	CONN-75909	NA Miata 26 Way ECU Plug Kit
16 Way Connector Pigtail	CONN-85907
22 Way Connector Pigtail	CONN-85908
26 Way Connector Pigtail	CONN-85909

Applications

NA Miata
Some other applications not specifically listed

Specifications

Parameter Value
Number of Ways 64
Gender Receptacle/Female
Terminal Size 1mm
Terminal Type Flat
Min. Wire Gauge 22
Max. Wire Gauge 16
