GM Delphi / Packard - 3 way GT 150 3.5mm Centerline Connector Plug Pigtail for some Delphi TPS & Ignition Coils (mushroom keyway)	Part # CONN-85731

Pricing
1 +	$9.99
25 +	$9.49
100 +	$8.99
500 +	$5.99
1000 +	$4.75
Information
Bmotorsports Part #	CONN-85731
Availability	In Stock
Shipping Weight	0.05 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

GM Delphi / Packard - 3 way GT 150 3.5mm Centerline Connector Plug Pigtail for some Delphi TPS & Ignition Coils (mushroom keyway). Preassembled and includes connector, front lock, seals, and terminals already crimped on 12 inch wire leads. A completed pigtail is provided.

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Connector Only	CONN-52210	GM Delphi / Packard - 3 way GT 150 3.5mm Centerline Connector Plug for some Delphi TPS & Ignition Coils (mushroom keyway)
Terminals	CONN-56468	GM Delphi / Packard - GT 150 3.5mm Centerline Female Terminal, 18 gauge [ .75 - .8mm2] Tin Plated
Seals	CONN-56559	GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only
Connector Kit	CONN-75731	GM Delphi / Packard - 3 way GT 150 3.5mm Centerline Connector Plug Kit for some Delphi TPS & Ignition Coils (mushroom keyway)
Connector Pigtail	CONN-85731	GM Delphi / Packard - 3 way GT 150 3.5mm Centerline Connector Plug Pigtail for some Delphi TPS & Ignition Coils (mushroom keyway)
Mating Parts
Terminals	CONN-56466	GM Delphi / Packard - GT 150 3.5mm Centerline Male Terminal, 18 gauge [ .75 - .8mm2] Tin Plated
Connector Housing	CONN-100726	3 Way 150.2 & Gt 150 3.5mm centerline Receptacle Connector
Connector Kit	CONN-75860	3 Way 150.2 & Gt 150 3.5mm centerline Receptacle Connector Kit
Pigtail	CONN-85860	3 Way 150.2 & Gt 150 3.5mm centerline Receptacle Connector Pigtail
Extensions

Specifications

Parameter Value
Number of Ways 3
Gender Plug/Male
Terminal Size 1.5mm
Min. Wire Gauge 18
Max. Wire Gauge 18

This product contains the following items:
	» 15 x Labor $0.25/minute Part # LABR-00001
	» 3 x 18AWG Automotive TXL Wire Black Part # WIRE-00459s
	» 3 x GM Delphi / Packard - GT 150 3.5mm Centerline Female Terminal, 18 gauge [ .75 - .8mm2] Tin Plated Part # CONN-56468
	» 3 x GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only Part # CONN-56559
	» 1 x GM Delphi / Packard - 3 way GT 150 3.5mm Centerline Connector Plug for some Delphi TPS & Ignition Coils (mushroom keyway) Part # CONN-52210
