GM Delphi / Packard - 8-way (1 blocked) Metripack 150 sealed connector pair	Part # CONN-200052

Pricing
1 +	$13.99
5 +	$13.50
25 +	$12.99
50 +	$12.50
100 +	$10.99
500 +	$7.99
Information
Bmotorsports Part #	CONN-200052
Availability	In Stock
Shipping Weight	0.05 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

GM Delphi / Packard - 8-way (1 blocked) Metripack 150 sealed connector pair

Contains Mating connector kits CONN-75599 GM Delphi / Packard - 8 way metripack 150 sealed female assembly Kit for main coil bank connector, gray; and CONN-75594 GM Delphi / Packard - 8 way metripack 150 sealed male assembly Connector Kit for main coil bank connector, gray

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Terminals	CONN-56256	GM Delphi / Packard - Sealed Metri-Pack 150 ( Metripack ) Female Terminal ( 20 - 16 gauge )
Seals	CONN-56058	GM Delphi / Packard - Metripack 150 2.85-2.03mm Cable Seal, Dark Red - 18-14 AWG
Connector Assembly	CONN-52359	GM Delphi / Packard - 8 way (1 blocked) metripack 150 sealed male assembly for main coil bank connector, gray
Connector Kit	CONN-75594	GM Delphi / Packard - 8 way (1 blocked) metripack 150 sealed male assembly Connector Kit for main coil bank connector, gray
Pigtail	CONN-85594	GM Delphi / Packard - 8 way (1 blocked) metripack 150 sealed male assembly for main coil bank connector Pigtail, gray
Mating Parts
Terminals	CONN-56260	GM Delphi / Packard - Sealed Metri-Pack 150 ( Metripack ) Male Terminal ( 20 - 16 gauge )
Seals	CONN-56058	GM Delphi / Packard - Metripack 150 2.85-2.03mm Cable Seal, Dark Red - 18-14 AWG
Connector Assembly	CONN-52360	GM Delphi / Packard - 8 way (1 blocked) metripack 150 sealed female assembly for main coil bank connector, gray
Connector Kit	CONN-75599	GM Delphi / Packard - 8 way (1 blocked) metripack 150 sealed female assembly Kit for main coil bank connector, gray
Pigtail	CONN-85599	GM Delphi / Packard - 8 way (1 blocked) metripack 150 sealed female pigtail for main coil bank connector, gray
Extension
Extension	CONN-85751	GM Delphi / Packard - LS Engine Coil Bank Extender Harness
Pair Kit
Connector Pair Kit	CONN-200052	GM Delphi / Packard - 8-way (1 blocked) Metripack 150 sealed connector pair

Specifications

Parameter Value
Number of Ways 7
Terminal Size 1.5mm
Min. Wire Gauge 20
Max. Wire Gauge 16

Applications

This product contains the following items:
	» 8 x GM Delphi / Packard - Sealed Metri-Pack 150 ( Metripack ) Female Terminal ( 20 - 16 gauge ) Part # CONN-56256
	» 8 x GM Delphi / Packard - Sealed Metri-Pack 150 ( Metripack ) Male Terminal ( 20 - 16 gauge ) Part # CONN-56260
	» 16 x GM Delphi / Packard - Metri-Pack 150 (Metripack) Cable Seal ( 20 - 16 gauge ), white Part # CONN-56057
	» 1 x GM Delphi / Packard - TPA for 8 way metripack 150 sealed male assembly for main coil bank connector, gray Part # CONN-52356
	» 1 x GM Delphi / Packard - TPA for 8 way metripack 150 sealed female assembly for main coil bank connector, black Part # CONN-52358
	» 1 x GM Delphi / Packard - 8 way (1 blocked) metripack 150 sealed female connector for main coil bank, gray Part # CONN-52357
	» 1 x GM Delphi / Packard - 8 way (1 blocked) metripack 150 sealed male connector for main coil bank, gray Part # CONN-52355
