1 Way Oil Pressure Sender (OSW, MOPS), Knock Sensor Connector Plug (Toyota # 90980-11363)	Part # CONN-100724

Pricing
1 +	$5.99
50 +	$5.75
100 +	$5.49
Information
Bmotorsports Part #	CONN-100724
Availability	In Stock
Shipping Weight	0.05 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

1 Way Oil Pressure Sender (OSW, MOPS), Knock Sensor Connector Plug (Toyota # 90980-11363). Connector ONLY. Terminals and seals NOT included.

Oil Pressure Sender Connector on thousands of Toyota & Lexus applications. The oil pressure sending unit is often found near the oil filter on many Toyota engines, and this is but one of many connectors for the various senders used over the years. Can also be found on the high lift valve mechanism on 2ZZ-GE engines.

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Terminals	CONN-11856	Sumitomo TS / SL Female Terminal 0.5 - 1.25 mm2 ( 20 - 16 AWG )
Seals	CONN-00145	Sumitomo HM / MT / TS Sealed Series wire seal, black ( 20 - 16 gauge )
Connector Housing	CONN-100724	1 Way Oil Pressure Sender (OSW, MOPS), Knock Sensor Connector Plug (Toyota # 90980-11363)
Connector Kit	CONN-76068	1 Way Oil Pressure Sender (OSW, MOPS), Knock Sensor Connector Kit (Toyota # 90980-11363)
Pigtail	CONN-86068	1 Way Oil Pressure Sender (OSW, MOPS), Knock Sensor Connector Pigtail (Toyota # 90980-11363)

Applications

Toyota Oil Pressure Sender Connector
Lexus Oil Pressure Sender Connector
1ZZ-FE Oil Pressure Sender Connector
2ZZ-GE Oil Pressure Sender Connector (OPS)
2ZZ-GE Lift Oil Pressure Sender Connector (MOPS)

Specifications

Parameter Value
Number of Ways 1
Gender Plug/Male
Terminal Size 2.3mm
Terminal Type Flat
Min. Wire Gauge 22
Max. Wire Gauge 16

Used In

Part #	Description
CONN-76068	1 Way Oil Pressure Sender (OSW, MOPS), Knock Sensor Connector Kit (Toyota # 90980-11363)
CONN-86068	1 Way Oil Pressure Sender (OSW, MOPS), Knock Sensor Connector Pigtail (Toyota # 90980-11363)
