Sumitomo 8-way TS 025 Receptacle Kit Toyota 90980-12519	Part # CONN-76057

Pricing
1 +	$8.99
15 +	$7.49
Information
Bmotorsports Part #	CONN-76057
Availability	In Stock
Shipping Weight	0.02 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

Sumitomo 8-way TS 025 Receptacle Kit Toyota 90980-12519. Connector kit. Terminals and seals ARE included.

Used on a wide variety of Toyota & Lexus applications as the device side or inline connection.
Also used to connect to Mitsubishi Outlander II LED headlamps / headlight housings
Also used as an inline connection on some Ducati Motorcycles for throttle body connections

Associated & Mating Parts

Relationship	Part #	Description
Associated Connectors
Connector Only	CONN-100980	Sumitomo 8-way TS 025 Receptacle Housing Toyota 90980-12519
Terminals	CONN-100954	Sumitomo TS 025 Male Terminal 0.22 - 0.5mm2 (24 - 20AWG)
Seals	CONN-100515	Sumitomo TS 025 Seal 1.6 - 1.7mm
Connector Kit	CONN-76057	Sumitomo 8-way TS 025 Receptacle Kit Toyota 90980-12519
Connector Pigtail	CONN-86057	Sumitomo 8-way TS 025 Receptacle Pigtail Toyota 90980-12519
Mating Connectors
Connector Only	CONN-100513	Sumitomo 8-way TS 025 Plug Housing Toyota 90980-12520
Terminals	CONN-100514	Sumitomo TS 025 Female Terminal 0.22 - 0.5mm2 (24 - 20AWG)
Seals	CONN-100515	Sumitomo TS 025 Seal 1.6 - 1.7mm
Connector Kit	CONN-75875	Sumitomo 8-way TS 025 Connector Plug Kit Toyota 90980-12520
Connector Pigtail	CONN-85875	Sumitomo 8-way TS 025 Connector Plug Pigtail

Applications

Applications:

Lexus 8 Way Connector
Toyota 8 Way Connector
Toyota PN 90980-12519
Ducati Throttle Position Sensor Connector
Ducati TPS Connector

Specifications

Parameter Value
Number of Ways 8
Gender Receptacle/Female
Terminal Type Flat
Min. Wire Gauge 24
Max. Wire Gauge 20

This product contains the following items:
	» 9 x Sumitomo TS 025 Seal 1.6 - 1.7mm Part # CONN-100515
	» 9 x Sumitomo TS 025 Male Terminal 0.22 - 0.5mm2 (24 - 20AWG) Part # CONN-100954
	» 1 x Sumitomo 8-way TS 025 Receptacle Housing Toyota 90980-12519 Part # CONN-100980
