GM Delphi / Packard - O2 extension Harness, gray	Part # CONN-85650

Pricing
1 +	$17.99
5 +	$17.49
10 +	$16.99
25 +	$16.49
50 +	$15.99
100 +	$15.49
250 +	$14.49
Information
Bmotorsports Part #	CONN-85650
Availability	In Stock
Shipping Weight	0.2 Lbs.
Shipping Location	VA (Shipping Info)
Options
Length
	Quantity:

Description

GM Delphi / Packard - O2 extension Harness, gray

TPA = Terminal Position Assurance, prevents terminals from backing out of connector

CPA = Connector Position Assurance, prevents connectors from coming loose from one another. This is a special CPA made for this type of application, remember to put the "loop" part of this cpa around the wires to prevent the CPA from being lost when you are disconnecting or connecting the connectors from one another.

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Terminal	CONN-56256	GM Delphi / Packard - Sealed Metri-Pack 150 ( Metripack ) Female Terminal ( 20 - 16 gauge )
Seal	CONN-56057	GM Delphi / Packard - Metri-Pack 150 (Metripack) Cable Seal ( 20 - 16 gauge ), white
Connector only	CONN-02068	GM Delphi / Packard - Gray Male O2 sensor connector with 5 pins (1 blocked) connector assembly (connector and TPA)
Connector kit	CONN-75562	GM Delphi / Packard - Gray Male O2 sensor connector kit with 5 pins (1 blocked) + TPA + CPA
Connector pigtail	CONN-85562	GM Delphi / Packard - Gray Male O2 sensor connector pigtail with 5 pins (1 blocked) + CPA
Mating Parts
Terminal	CONN-56260	GM Delphi / Packard - Sealed Metri-Pack 150 ( Metripack ) Male Terminal ( 20 - 16 gauge )
Seal	CONN-56057	GM Delphi / Packard - Metri-Pack 150 (Metripack) Cable Seal ( 20 - 16 gauge ), white
Connector only	CONN-02067	GM Delphi / Packard - Gray Female O2 sensor connector with 5 pins (1 blocked), assembly (Connector and TPA)
Connector kit	CONN-75561	GM Delphi / Packard - Gray Female O2 sensor connector kit with 5 pins (1 blocked) + TPA + CPA
Connector Pigtail	CONN-85561	GM Delphi / Packard - Gray Female O2 sensor connector pigtail with 5 pins (1 blocked) + CPA
Extension
Extension	CONN-85650	GM Delphi / Packard - O2 extension Harness, gray
Pair Kit
Connector Pair Kit	CONN-200041	GM Delphi / Packard - Sealed 5-pin 1 missing Metripack 150 O2 connector pair, gray

Specifications

Parameter Value
Number of Ways 4
Terminal Size 1.5mm
Terminal Type Flat
Min. Wire Gauge 20
Max. Wire Gauge 16

This product contains the following items:
	» 20 x Labor $0.25/minute Part # LABR-00001
	» 4 x GM Delphi / Packard - Sealed Metri-Pack 150 ( Metripack ) Female Terminal ( 20 - 16 gauge ) Part # CONN-56256
	» 4 x GM Delphi / Packard - Sealed Metri-Pack 150 ( Metripack ) Male Terminal ( 20 - 16 gauge ) Part # CONN-56260
	» 8 x GM Delphi / Packard - Metri-Pack 150 (Metripack) Cable Seal ( 20 - 16 gauge ), white Part # CONN-56057
	» 2 x GM Delphi / Packard - TPA for o2 sensor connectors 5 pins 1 missing Part # CONN-02055
	» 1 x GM Delphi / Packard - CPA for Metri-Pack ( Metripack ) 150 connectors Part # CONN-02059
	» 1 x 3/8 in. Diameter x 4ft. Black 3:1 Adhesive Lined Polyolefin Heat Shrink Tubing, 110 C Part # WIRE-56258
	» 4 x 18AWG Automotive Teflon Mil-Spec Wire Black Part # WIRE-00489s
	» 1 x Insultherm Hi-Temp braided sleeving - 1/4 inch Part # WIRE-63555
	» 1 x GM Delphi / Packard - Gray Female O2 sensor connector with 5 pins (1 blocked) Part # CONN-02065
	» 1 x GM Delphi / Packard - Gray Male O2 sensor connector with 5 pins (1 blocked) Part # CONN-02066
